| Nama Wahi | LTM201M1-L01 |
| Waitohu | Samsung |
| Rahi | 20.1 |
| Taupānga | DMPC |
| Whakatau | 1680×1050 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTM201M1-L01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 20.1 inch |
| resolution | 1680(RGB)×1050 , WSXGA+ |
| display mode | S-PVA, Normally Black, Transmissive |
| active area | 433.44×270.9 mm |
| outline | 459.4×296.4 mm |
| surface | Antiglare (Haze 44%), Hard coating (3H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 16 (Typ.)(Tr+Td); 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | DMPC |
