| Nama Wahi | NL10276BC30-24D |
| Waitohu | NLT |
| Rahi | 15.0 |
| Taupānga | NBPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 320 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL10276BC30-24D |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 304.128×228.096 mm |
| outline | 317.3×242.2×10 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Clear, Hard coating (2H), Antireflection |
| brightness | 320 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193172% |
| response time | TBD |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
