| Nama Wahi | NL10276AC28-05R |
| Waitohu | NLT |
| Rahi | 14.1 |
| Taupānga | DMPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 220 |
| CR | 150:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL10276AC28-05R |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 14.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 285.696×214.272 mm |
| outline | 330×255×20.5 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 150:1 (Typ.) |
| display colors | 262K (6-bit), CIE193140% |
| response time | 11/40 (Typ.)(Tr/Td) |
| viewing angle | 50/50/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 2 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
