| Nama Wahi | B156HW01 V7 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | NBPC |
| Whakatau | 1920×1080 |
| Te tito | LCM |
| Tirohanga | 270 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B156HW01 V7 20 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.6 inch |
| resolution | 1920(RGB)×1080 , FHD |
| display mode | TN, Normally White, Transmissive |
| active area | 344.16×193.59 mm |
| outline | 359.3×209.5×5.7 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%), Hard coating (3H), Reflection 5.0% (Max.) |
| brightness | 270 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193195% |
| response time | 8 (Typ.)(Tr+Td); |
| viewing angle | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| B156HAN01.2 | AUO | 15.6 | 1920×1080 |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B156HTN03.3 | AUO | 15.6 | 1920×1080 |
| B156HW01 V0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V3 | AUO | 15.6 | 1920×1080 |
| B156HW01 V4 | AUO | 15.6 | 1920×1080 |
| B156HW01 V7 | AUO | 15.6 | 1920×1080 |
| B156HW02 V1 | AUO | 15.6 | 1920×1080 |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| LP133WH2-TLN4 | LG Display | 13.3 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| LP140WH8-TLA1 | LG Display | 14.0 | 1366×768 |
| LTD133EWCF | TOSHIBA | 13.3 | 1280×800 |
| LTN154P3-L05 | Samsung | 15.4 | 1680×1050 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
| N154I3-L03 | Innolux | 15.4 | 1280×800 |
| N173HGE-L11 | Innolux | 17.3 | 1920×1080 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
