| Nama Wahi | LTN154P3-L05 |
| Waitohu | Samsung |
| Rahi | 15.4 |
| Taupānga | NBPC |
| Whakatau | 1680×1050 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTN154P3-L05 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.4 inch |
| resolution | 1680(RGB)×1050 , WSXGA+ |
| display mode | TN, Normally White, Transmissive |
| active area | 331.38×207.11 mm |
| outline | 344×222×6.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Antiglare (Haze 40%), Hard coating (3H) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 300:1 (Min.) |
| display colors | 262K (6-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 60/60/40/50 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN154AT01-A03 | Samsung | 15.4 | 1280×800 |
| LTN154AT08-001 | Samsung | 15.4 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| LTN154MT02-W01 | Samsung | 15.4 | 1680×1050 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| LTN154P3-L05 | Samsung | 15.4 | 1680×1050 |
| LTN154U2-L03 | Samsung | 15.4 | 1920×1200 |
| LTN154X3-L01 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L09-0 | Samsung | 15.4 | 1280×800 |
| B140XW02 V0 | AUO | 14.0 | 1366×768 |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| LP133WH1-TLA2 | LG Display | 13.3 | 1366×768 |
| LP173WD1-TLA1 | LG Display | 17.3 | 1600×900 |
| LQ164M1LG4B | SHARP | 16.4 | 1920×1080 |
| N133HSE-EB1 | Innolux | 13.3 | 1920×1080 |
| N140BGK-L33 | Innolux | 14.0 | 1366×768 |
