| Nama Wahi | M080AWT8 R1 |
| Waitohu | IVO |
| Rahi | 8.0 |
| Taupānga | Automotive Display |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | IVO |
| model | M080AWT8 R1 |
| diagonal size | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×600 [WSVGA] 148PPI |
| configuration | RGB Vertical Stripe |
| active area | 176.64(H)×99.36(V) mm |
| outline dim. | 192.8(H)×116.9(V) ×8.35(D) mm |
| bezel area | 178.84(H)×101.56(V) mm |
| treatment | Antiglare |
| luminance | 670 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | 6 o'clock |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K/16.7M 72% NTSC |
| light source | WLED [3S7P] , 30K hours , W/O Driver |
| weight | 240g (Max.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
