| Nama Wahi | LSUGC202XA |
| Waitohu | ALPS |
| Rahi | 8.9 |
| Taupānga | |
| Whakatau | 640×240 |
| Te tito | LCM |
| Tirohanga | 160 |
| CR | 3:1 |
| Nga Tae | Monochrome |
| Whakamuri | CCFL |
| Atanga | Parallel Data |
| panel brand | ALPS |
| panel model | LSUGC202XA |
| panel type | STN-LCD , LCM |
| panel size | 8.9 inch |
| resolution | 640×240 , HVGA |
| display mode | STN, Blue mode |
| active area | 211.18×79.18 mm |
| outline | 270.2×112.2 mm |
| surface | |
| brightness | 160 cd/m² (Typ.) |
| contrast ratio | 3 : 1 (Typ.) |
| display colors | Monochrome |
| response time | 250/120 (Typ.)(Tr/Td) |
| viewing angle | 30/30/15/30 (Min.)(CR≥10)(L/R/U/D) |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (4-bit), 12 pins |
| rohs: |
