TPO TD043MTEA1 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

TD043MTEA1


Waitohu
TPO
Rahi
4.3
Taupānga
Whakatau
800×480
Te tito
LCM
Tirohanga
300
CR
400:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
TTL
In Stock
3800
Whakatakotoranga

Nama Wahi TD043MTEA1
WaitohuTPO
Rahi4.3
Taupānga
Whakatau800×480
Te titoLCM
Tirohanga300
CR400:1
Nga Tae16.7M
WhakamuriWLED
AtangaTTL
panel brandTPO
panel modelTD043MTEA1
panel type LTPS TFT-LCD , LCM
panel size4.3 inch
resolution800(RGB)×480 , WVGA
display modeNormally Black, Transmissive
active area93.6×56.16 mm
outline100.6×68.45 mm
surface
brightness300 cd/m² (Typ.)
contrast ratio400:1 (Typ.)
display colors16.7M (8-bit)
response time30 (Typ.)(Tr+Td)
viewing angle85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type8S1PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 8-bit), 60 pins
input voltage3.3/5.0/-5V (Typ.)(VCC/VDDP/VDDN)
Tauira Whanau
AT043TN13 TP Innolux 4.3 480×272
AT043TN24 V.1 Innolux 4.3 480×272
C043FW01 V0 AUO 4.3 480×234
DLC0430LZG Other 4.3 480×272
LH430WV1-SD02 LG Display 4.3 480×800
LMS430HF19 Samsung 4.3 480×272
LQ043T3DX03 SHARP 4.3 480×272
TD043MGEB1 TPO 4.3 800×480
TD043MTEA1 TPO 4.3 800×480
TD043MTEA2 TPO 4.3 800×480
Hua wera
AL2002A Other 2.9 20×2
CLAA101ND07CW CPT 10.1 1024×600
DMC-16202NY-LY-BJE-BLN Kyocera 2.3 16×2
DMC-40202NY-LY-ARE-AZN Kyocera 5.8 40×2
LS013B4DN01 SHARP 1.35 96×96
LS025Q1UC01 SHARP 2.5
LTA090B400F TOSHIBA 9.0 800×480
OEL9M0083-R-E Other 0.96 128×64
OEL9M5003-G-E Other 2.7 128×64
TD043MGEB1 TPO 4.3 800×480
