| Nama Wahi | LS055R1SC01 |
| Waitohu | SHARP |
| Rahi | 5.5 |
| Taupānga | MPH |
| Whakatau | 1440×2560 |
| Te tito | LCM |
| Tirohanga | 480 |
| CR | 1300:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | SHARP |
| panel model | LS055R1SC01 |
| panel type | CG-Silicon , LCM |
| panel size | 5.5 inch |
| resolution | 1440(RGB)×2560 , Quad-HD |
| display mode | New Mode2, Normally Black, Transmissive |
| active area | 68.04×120.96 mm |
| outline | 70.87×128.45×1.45 mm |
| surface | Hard coating (3H) |
| brightness | 480 cd/m² (Typ.) |
| contrast ratio | 1300:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 35 (Max.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 45 pins |
| input voltage | 1.8/5.75/-5.75V (Typ.)(IOVDD/AVDD+/AVDD-) |
| application | MPH |
