| Nama Wahi | TM022HDHT1-05 |
| Waitohu | Tianma |
| Rahi | 2.2 |
| Taupānga | MPH |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 90 |
| CR | 120:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM022HDHT1-05 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.2 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | ECB, Normally White, Transflective |
| active area | 33.84×45.12 mm |
| outline | 40.6×56.6 mm |
| surface | Clear, Hard coating (3H) |
| brightness | 90 cd/m² (Typ.) |
| contrast ratio | 120:1 (Typ.)(Transmissive) |
| display colors | 262K (6-bit), CIE193130% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 40/45/48/45 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| input voltage | 2.8V (Typ.)(VDD) |
| application | MPH |
| AMS410GC01-0 | Samsung | 4.1 | 480×800 |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| LH520WF1-SD01 | LG Display | 5.2 | 1080×1920 |
| LS030Y7PW01 | SHARP | 3.0 | |
| LS040T8LX02 | SHARP | 4.0 | 480×854 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| TX08D13VM0AAA | KOE | 3.0 | 240×400 |
