| Nama Wahi | TD035SHED1 |
| Waitohu | TPO |
| Rahi | 3.5 |
| Taupānga | MPH |
| Whakatau | 480×640 |
| Te tito | LCM |
| Tirohanga | 170 |
| CR | 200:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TPO |
| panel model | TD035SHED1 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.5 inch |
| resolution | 480(RGB)×640 , VGA |
| display mode | TN, Normally White, Transflective |
| active area | 53.28×71.04 mm |
| outline | 64×85 mm |
| surface | |
| brightness | 170 cd/m² (Typ.) |
| contrast ratio | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| display colors | 262K (6-bit), CIE193137% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| input voltage | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| application | MPH |
