| Nama Wahi | TD035STEB1 |
| Waitohu | TPO |
| Rahi | 3.5 |
| Taupānga | MPH |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 100 |
| CR | 80:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | Toppoly |
| panel model | TD035STEB1 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.5 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | TN, Normally White, Transflective |
| active area | 53.64×71.52 mm |
| outline | 64×85×4.9 mm |
| surface | |
| brightness | 100 cd/m² (Typ.) |
| contrast ratio | 80:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| display colors | 262K (6-bit), CIE193139% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 45/60/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| input voltage | 3.3/4.5/11.1/-7V (Typ.)(VCC3/VCC5/VDD/VEE) |
| application | MPH |
