| Nama Wahi | H546TAN01.0 |
| Waitohu | AUO |
| Rahi | 5.5 |
| Taupānga | MPH |
| Whakatau | 720×1280 |
| Te tito | LCM |
| Tirohanga | 440 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | AUO |
| panel model | H546TAN01.0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.5 inch |
| resolution | 720(RGB)×1280 , WXGA |
| display mode | AHVA, Normally Black, Transmissive |
| active area | 68.04×120.96 mm |
| outline | 72.3×130.39×1.75 mm |
| surface | |
| brightness | 440 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 35 (Max.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | MIPI (4 data lanes) |
| input voltage | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| application | MPH |
