| Nama Wahi | LAM170M023A |
| Waitohu | JDI |
| Rahi | 17.0 |
| Taupānga | MD |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 240 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | JDI |
| panel model | LAM170M023A |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 368×306×20.4 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 240 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193174% |
| response time | 10/12 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3 stringsWLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | MD |
