| Nama Wahi | R300M1-L01 |
| Waitohu | Innolux |
| Rahi | 30.0 |
| Taupānga | MD |
| Whakatau | 4096×2560 |
| Te tito | LCM |
| Tirohanga | 1200 |
| CR | 800:1 |
| Nga Tae | Grayscale |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | CMO |
| panel model | R300M1-L01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 30.0 inch |
| resolution | 4096(LCR)×2560 , DQSXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 645.12×403.2 mm |
| outline | 678×448×49.5 mm |
| surface | Antiglare (Haze 40%), Hard coating (3H) |
| brightness | 1200 cd/m² (Typ.) |
| contrast ratio | 800:1 (Min.) |
| display colors | Grayscale (10-bit) |
| response time | 50/15 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frequency | 50Hz |
| lamp type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 10-bit), 82 pins |
| input voltage | 12.0V (Typ.) |
| application | MD |
