| Nama Wahi | HV208QX1-100 |
| Waitohu | HYDIS |
| Rahi | 20.8 |
| Taupānga | MD |
| Whakatau | 2048×1536 |
| Te tito | LCM |
| Tirohanga | 800 |
| CR | 700:1 |
| Nga Tae | Grayscale |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HV208QX1-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 20.8 inch |
| resolution | 2048(LCR)×1536 , QXGA |
| display mode | AFFS, Normally Black, Transmissive |
| active area | 423.9×318 mm |
| outline | 457×350 mm |
| surface | Antiglare (Haze 13%), Hard coating (3H) |
| brightness | 800 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | Grayscale (8-bit) |
| response time | 15/20 (Typ.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 8-bit), 70 pins |
| input voltage | 12.0V (Typ.) |
| application | MD |
