| Nama Wahi | LTN170U1-L02 |
| Waitohu | Samsung |
| Rahi | 17.0 |
| Taupānga | NBPC |
| Whakatau | 1920×1200 |
| Te tito | LCM |
| Tirohanga | |
| CR | |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTN170U1-L02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1920(RGB)×1200 , WUXGA |
| display mode | TN, Normally White, Transmissive |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | |
| brightness | |
| contrast ratio | |
| display colors | 262K (6-bit) |
| response time | |
| viewing angle | |
| frequency | 60Hz |
| lamp type | CCFL |
| signal interface | LVDS (2 ch, 6-bit) |
| application | NBPC |
