| Nama Wahi | CLAA080NA73 CW |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | Industrial Automotiv |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3S13P |
| Atanga | |
| panel brand | CPT |
| panel size | 8.0" |
| resolution | 1024(RGB)×600, WSVGA, 148PPI |
| display area | 176.64(W)×99.36(H) mm |
| outline size | 192.8(W)×116.9(H) ×8.35(D) mm |
| brightness | 600 cd/m² (Typ.) |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 262K/16.7M 50% NTSC |
| frequency | 60Hz |
| weight | 220g (Typ.) |
| panel model | CLAA080NA73 CW |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 180.1(W)×103.4(H) mm |
| surface | Antiglare |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 12 (Typ.)(Tr+Td) |
| lamp type | 3S13P WLED , 30K hours , Without Driver |
| touch screen | Without |
| application | Industrial Automotive Display |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
