| Nama Wahi | CLAA070WQ62 XG |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| brand | CPT |
| diagonal size | 7.0 inch |
| pixel format | 800(RGB)×1280 [WXGA] 215PPI |
| active area | 94.2(H)×150.72(V) mm |
| bezel area | - |
| luminance | 350 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| support color | 16.7M 70% NTSC |
| weight | - |
| frame rate | 60Hz |
| interface type | MIPI (4 data lanes) , 39 pins FPC |
| power supply | 1.8/3.3/15/-10V (Typ.)(VDDI/VCI/VGH/VGL) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model | CLAA070WQ62 XG |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 99.6(H)×161.62(V) ×4.05(D) mm |
| treatment | Hard coating |
| contrast ratio | 800:1 (Typ.) (TM) |
| response time | 30 (Typ.)(Tr+Td) |
| operating mode | FFS, Normally Black, Transmissive |
| light source | WLED [3S6P] , 15K hours , W/O Driver |
| designed for | Pad & Tablet |
| touch panel | On-Cell Touch |
