| Nama Wahi | CLAA070LF05CW |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 400:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CPT |
| panel model | CLAA070LF05CW |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 154.08×85.92 mm |
| outline | 164.9×100×3.7 mm |
| surface | Antiglare |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S6PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 50 pins |
| input voltage | 3.3/9.6/18.0/-6 (Typ.)(DVDD/AVDD/VGH/VGL) |
| application | CNS |
