| Nama Wahi | CLAA070NB02CT |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | MP4 |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | RSDS |
| panel brand | CPT |
| panel model | CLAA070NB02CT |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 153.6×90 mm |
| outline | 162.9×102×5.8 mm |
| surface | Antiglare |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | WLEDWithout Driver |
| signal interface | RSDS (1 Channel), 61 pins |
| input voltage | 3.3/9.6/18/-6V (Typ.)(VCC/AVDD/VDDG/VEEG) |
| rohs: | |
| application | MP4 |
