| Nama Wahi | B080EAK02.2 |
| Waitohu | AUO |
| Rahi | 8.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4S5P |
| Atanga | MIPI |
| panel brand | AUO |
| panel model | B080EAK02.2 |
| panel size | 8.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×1280, WXGA, 188PPI |
| pixel format | RGB Vertical Stripe |
| display area | 107.64(W)×172.224(H) mm |
| bezel opening | - |
| outline size | 113.72(W)×183.764(H) ×4.1(D) mm |
| surface | Glare (Haze 0%) |
| brightness | 360 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | AHVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 25 (Typ.)(Tr+Tf) |
| display colors | 16.7M 58% NTSC |
| lamp type | 4S5P WLED , 15K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 120g (Max.) |
| application | Pad & Tablet |
| signal interface | MIPI (4 data lanes) , 39 pins Connector |
| input voltage | 1.8/3.3V (Typ.)(VCC1/VC2) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
