| Nama Wahi | AM-1024600LHMQW-16H |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 6S6P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| model name | AM-1024600LHMQW-16H |
| screen size | 10.1 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 117PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 222.72 × 125.28 (H×V) |
| outline(mm) | 235 × 145.8 × 7.3 (H×V×D) |
| bezel area(mm) | 225.92 × 128.48 (H×V) |
| treatment | Antiglare |
| luminance | 250 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10) |
| response | 4/12 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 47% NTSC |
| backlight | 6S6P WLED , 20K hours , With LED Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6-bit) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
