| Nama Wahi | AM-1024600K8TMQW-T09H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | 5S3P |
| Atanga | |
| manufacturer | AMPIRE |
| model name | AM-1024600K8TMQW-T09H |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 169PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 153.6 × 90 (H×V) |
| outline(mm) | 165.5 × 104.4 × 10.77 (H×V×D) |
| bezel area(mm) | - |
| treatment | Glare (Haze 0%), Hard coating |
| luminance | 425 cd/m² (Typ.) |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| response | 20/20 (Typ.)(Tr/Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M |
| backlight | 5S3P WLED , 30K hours , With LED Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | PCAP |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
