| Nama Wahi | AM-1024600K5TMQW-T00H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | 5S3P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| model name | AM-1024600K5TMQW-T00H |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 169PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 153.6 × 90 (H×V) |
| outline(mm) | 165.5 × 103 × 11.02 (H×V×D) |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| response | 20/20 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M |
| backlight | 5S3P WLED , 30K hours , With LED Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| signal type | LVDS (1 ch, 8-bit) , Connector 20 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
