| Nama Wahi | AM-1024600ITZQW-00H |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-1024600ITZQW-00H |
| panel size | 10.1" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×600, WSVGA, 117PPI |
| pixel format | RGB Vertical Stripe |
| display area | 222.72(W)×125.28(H) mm |
| bezel opening | - |
| outline size | 234.9(W)×143(H) ×4.9(D) mm |
| surface | Antiglare, Hard coating |
| brightness | 550 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 12/28 (Typ.)(Tr/Td) |
| display colors | 262K/16.7M 70% NTSC |
| lamp type | WLED , 50K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | - |
| application | Industrial |
| signal interface | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| input voltage | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
