A030DN01 V0

A030DN01 V0
A030DN01 V0
A030DN01 V0 thumb A030DN01 V0 thumb
Waitohu
AUO
Rahi
3.0
Taupānga
DSC
Whakatau
320×240
Te tito
LCM
Tirohanga
250
CR
300:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
Serial RGB
In Stock
13647
Whakatakotoranga

Nama Wahi A030DN01 V0
WaitohuAUO
Rahi3.0
TaupāngaDSC
Whakatau320×240
Te titoLCM
Tirohanga250
CR300:1
Nga Tae16.7M
WhakamuriWLED
AtangaSerial RGB
panel brandAUO
panel modelA030DN01 V0
panel type a-Si TFT-LCD , LCM
panel size3.0 inch
resolution320(RGB)×240 , QVGA
display modeTN, Normally White, Transmissive
active area60×45 mm
outline70.2×51.4 mm
surfaceHard coating
brightness250 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colors16.7M (8-bit)
response time15/20 (Typ.)(Tr/Td)
viewing angle55/55/45/60 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type2S1PWLEDWithout Driver
signal interfaceSerial RGB (8-bit) + SPI, CCIR601/656, 40 pins
input voltage3.3/3.3V (Typ.)(VDD/VDDIO)
applicationDSC
