| Nama Wahi | TD030MHEB3 |
| Waitohu | TPO |
| Rahi | 3.0 |
| Taupānga | DSC |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | |
| CR | 270:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Serial RGB |
| panel brand | TPO |
| panel model | TD030MHEB3 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.0 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White |
| active area | 60.3×45 mm |
| surface | |
| brightness | |
| contrast ratio | 270 : 1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 30/10 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | WLED |
| signal interface | Serial RGB (8-bit) + SPI, 30 pins |
| input voltage | 3.3V (Typ.) |
| rohs: | |
| application | DSC |
