| Nama Wahi | A030DN01 V9 |
| Waitohu | AUO |
| Rahi | 3.0 |
| Taupānga | DSC |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 300:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Serial RGB |
| panel brand | AUO |
| panel model | A030DN01 V9 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 3.0 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 60×45 mm |
| outline | 70.2×51.4 mm |
| surface | Hard coating |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, CCIR601/656, 41 pins |
| input voltage | 3.3V (Typ.) |
| application | DSC |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| A030DW01 V3 | AUO | 3.0 | 320×240 |
| LS030B3UW01 | SHARP | 3.0 | 240×400 |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| A027DN03 V4 | AUO | 2.7 | 320×240 |
| A027DN03 V7 | AUO | 2.7 | 320×240 |
| A027DN03 V9 | AUO | 2.7 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| PA035XSL | E Ink | 3.5 | 320×234 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM035KDH03 | Tianma | 3.5 | 320×240 |
