| Nama Wahi | WG12232E-YYH-N#A |
| Waitohu | Winstar |
| Rahi | 2.2 |
| Taupānga | Industrial Instrumen |
| Whakatau | 122×32 |
| Te tito | STN-LCD , LCM |
| Tirohanga | |
| CR | 3:1 |
| Nga Tae | Monochrome |
| Whakamuri | YG-LED |
| Atanga | 8-bit |
| brand | Winstar |
| diagonal size | 2.2 inch |
| pixel format | 122×32 57PPI |
| active area | 53.64(H)×15.64(V) mm |
| bezel area | 60.0(H)×18.0(V) mm |
| luminance | - |
| view direction | 6 o'clock |
| viewing angle | 30/30/20/40 (Typ.)(CR≥2) |
| support color | Monochrome |
| weight | - |
| frame rate | - |
| interface type | 8-bit 6800/8080 parallel , 20 pins Pad |
| power supply | 5.0V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WG12232E-YYH-N#A |
| type | STN-LCD , LCM |
| configuration | Rectangle |
| outline dim. | 80(H)×36(V) ×10.2(D) mm |
| treatment | - |
| contrast ratio | 3:1 (Typ.) (TM) |
| response time | 100/100 (Typ.)(Tr/Td) |
| operating mode | STN, Yellow/Green (Positive), Transflective |
| light source | YG-LED , 100K hours , W/O Driver |
| designed for | Industrial Instruments & Meters |
| touch panel | Without |
