| Nama Wahi | DLC0220BMG |
| Waitohu | Other |
| Rahi | 2.2 |
| Taupānga | MPH |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 90 |
| CR | 120:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | DLC |
| panel model | DLC0220BMG 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.2 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | ECB, Normally White, Transflective |
| active area | 33.84×45.12 mm |
| outline | 40.6×56.6 mm |
| surface | Clear, Hard coating (3H) |
| brightness | 90 cd/m² (Typ.) |
| contrast ratio | 120:1 (Typ.)(Transmissive) |
| display colors | 262K (6-bit), CIE193130% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 40/45/48/45 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| input voltage | 2.8V (Typ.)(VDD) |
| application | MPH |
