Other HGS128321-B-EH-LV Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


HGS128321-B-EH-LV

HGS128321-B-EH-LV
HGS128321-B-EH-LV
HGS128321-B-EH-LV
HGS128321-B-EH-LV thumb HGS128321-B-EH-LV thumb HGS128321-B-EH-LV thumb
Waitohu
Other
Rahi
2.2
Taupānga
IA
Whakatau
128×32
Te tito
OLED
Tirohanga
120
CR
2000:1
Nga Tae
Mono(Blue)
Whakamuri
self
Atanga
CPU/SPI/I²C
In Stock
13005
Whakatakotoranga

Nama Wahi HGS128321-B-EH-LV
WaitohuOther
Rahi2.2
TaupāngaIA
Whakatau128×32
Te titoOLED
Tirohanga120
CR2000:1
Nga TaeMono(Blue)
Whakamuriself
AtangaCPU/SPI/I²C
panel brandTSINGTEK
panel modelHGS128321-B-EH-LV
panel type PM-OLED , OLED
panel size2.2 inch
resolution128×32
active area55.02×13.1 mm
outline66.5×35×10 mm
surface
brightness120 cd/m² (Typ.)
contrast ratio2000 : 1 (Min.)
display colorsMono(Blue)
viewing angle80/80/80/80 (Min.)(L/R/U/D)
driver icBuilt-in SSD1305
signal interface8-bit 6800/8080 parallel, 4-wire SPI, I²C, 20 pins
input voltage3.3V (Typ.)
applicationIA
