| Nama Wahi | TX20D33VM2BAC |
| Waitohu | KOE |
| Rahi | 8.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | CMOS |
| manufacturer | KOE |
| screen size | 8.0 inch |
| pixel number | 800(RGB)×480 (WVGA) 116PPI |
| active area(mm) | 174 × 104.4 (H×V) |
| bezel area(mm) | 187.0 × 108.4 (H×V) |
| luminance | - |
| viewing angle | 80/80/60/80 (Typ.)(CR≥10) |
| good view at | 6 o'clock |
| color depth | 262K |
| mass | 160g |
| refresh rate | 60Hz |
| signal type | CMOS (1 ch, 6-bit) , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| model name | TX20D33VM2BAC |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 189 × 120 × 8 (H×V×D) |
| treatment | - |
| contrast ratio | 600 : 1 (Typ.) (TM) |
| response | 20 (Typ.)(Tr+Td) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | WLED , 50K hours , No Driver |
| used for | Industrial |
| touchscreen | Without |
