| Nama Wahi | TMS156WX1-02TC |
| Waitohu | Tianma |
| Rahi | 15.6 |
| Taupānga | DMPC |
| Whakatau | 1366×768 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | LVDS |
| panel brand | AVIC |
| panel model | TMS156WX1-02TC |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 15.6 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 344.232×193.536 mm |
| surface | |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193160% |
| response time | 2/6 (Typ.)(Tr/Td) |
| viewing angle | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| B156HW01 V7 | AUO | 15.6 | 1920×1080 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| B156XW03 V0 | AUO | 15.6 | 1366×768 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH1-TLC1 | LG Display | 15.6 | 1366×768 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| TMS156WX1-01TB | Tianma | 15.6 | 1366×768 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
| HT190WG3-101 | BOE | 19.0 | 1440×900 |
| LM190E08-TLG3 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLL1 | LG Display | 19.0 | 1280×1024 |
| LM215WF8-TLA1 | LG Display | 21.5 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LTM340YP01 | Samsung | 34 | 3440×1440 |
| M270H1-L01 | Innolux | 27.0 | 1920×1080 |
| M270MWN1 R0 | IVO | 27.0 | 1920×1080 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
| TM150XG-26L06A | SANYO | 15.0 | 1024×768 |
