| Nama Wahi | TM123XDHP90 |
| Waitohu | TIANMA |
| Rahi | 12.3 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 10S4P |
| Atanga | LVDS |
| panel brand | TIANMA |
| panel model | TM123XDHP90 |
| panel size | 12.3" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×720, 166PPI |
| pixel format | RGB Vertical Stripe |
| display area | 292.32(W)×109.62(H) mm |
| bezel opening | - |
| outline size | 311(W)×130(H) ×15.7(D) mm |
| surface | Antiglare (Haze 28%) |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | - |
| display mode | SFT, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| display colors | 16.7M 98% sRGB |
| lamp type | 10S4P WLED , 10K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 490g (Typ.) |
| application | Industrial Outdoor High Brightness Automotive Display |
| signal interface | LVDS (2 ch, 8-bit) , 50 pins FPC |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
