| Nama Wahi | TX31D200VM0BAA |
| Waitohu | KOE |
| Rahi | 12.3 |
| Taupānga | IA |
| Whakatau | 1280×480 |
| Te tito | LCM |
| Tirohanga | 1000 |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | KOE |
| panel model | TX31D200VM0BAA |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.3 inch |
| resolution | 1280(RGB)×480 , DVGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 291.84×109.44 mm |
| outline | 320×130×12.6 mm |
| surface | Antiglare |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 262K (6-bit), CIE193170% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
