| Nama Wahi | TM028HDZ58 |
| Waitohu | TIANMA |
| Rahi | 2.8 |
| Taupānga | Mobile Phone |
| Whakatau | 240×320 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 65K/262K |
| Whakamuri | 1S4P |
| Atanga | Parallel |
| manufacturer | TIANMA |
| model name | TM028HDZ58 |
| screen size | 2.8 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 240(RGB)×320 (QVGA) 141PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 43.2 × 57.6 (H×V) |
| outline(mm) | - |
| luminance | - |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 60/60/60/50 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 65K/262K 55% NTSC |
| backlight | 1S4P WLED , No Driver |
| mass | - |
| used for | Mobile Phone |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | Parallel RGB (1 ch, 6-bit) + SPI |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
