| Nama Wahi | T230XW01 V1 |
| Waitohu | AUO |
| Rahi | 23.0 |
| Taupānga | LCTV |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | T230XW01 V1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 23.0 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 508.152×285.696 mm |
| outline | 546×318.3 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| response time | 7/1 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | LCTV |
| LC230W01-A2 | LG Display | 23.0 | 1280×768 |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLQ1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LTA230AN01 | Samsung | 23.0 | 1366×768 |
| NL12876AC39-01 | NLT | 23.0 | 1280×768 |
| T230XW01 V1 | AUO | 23.0 | 1366×768 |
| T230XW01 V2 | AUO | 23.0 | 1366×768 |
| HV320WXC-100 | BOE | 31.5 | 1366×768 |
| LC550WUD-SBM4 | LG Display | 55 | 1920×1080 |
| LTA216AT01 | Samsung | 21.6 | 1366×768 |
| LTA230A172F | TOSHIBA | 23.0 | 1280×768 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA750FJ01 | Samsung | 75 | 3840×2160 |
| LTF320AP06 | Samsung | 31.5 | 1366×768 |
| LTF550HF04-A05 | Samsung | 55 | 1920×1080 |
| V290BJ1-L01 | Innolux | 29.0 | 1366×768 |
| V420HJ1-LE6 | Innolux | 42 | 1920×1080 |
