| Nama Wahi | T230XW01 V2 |
| Waitohu | AUO |
| Rahi | 23.0 |
| Taupānga | LCTV |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 450:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | T230XW01 V2 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 23.0 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 508.152×285.696 mm |
| outline | 546×318.3 mm |
| surface | Antiglare (Haze 26%), Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 6/10 (Typ.)(Tr/Td) |
| viewing angle | 70/70/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | LCTV |
