| Nama Wahi | NL12876AC39-01 |
| Waitohu | NLT |
| Rahi | 23.0 |
| Taupānga | DMPC |
| Whakatau | 1280×768 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 350:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL12876AC39-01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 23.0 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | UA-SFT, Normally Black, Transmissive |
| active area | 501.12×300.672 mm |
| outline | 528×326 mm |
| surface | Hard coating (2H), Antireflection |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 10/13 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
