| Nama Wahi | R156B48-167-0101 |
| Waitohu | No Brand |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 8S6P |
| Atanga | LVDS |
| panel brand | No Brand |
| panel model | R156B48-167-0101 1 Compatible |
| panel size | 15.6" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1366(RGB)×768, WXGA, 100PPI |
| pixel format | RGB Vertical Stripe |
| display area | 344.232(W)×193.536(H) mm |
| bezel opening | - |
| outline size | 359.3(W)×209.5(H) ×5.5(D) mm |
| surface | Glare (Haze 0%) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 45/45/20/40 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | - |
| response time | 12 (Typ.)(Tr+Td) |
| display colors | 262K 45% NTSC |
| lamp type | 8S6P WLED , 15K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| shape style | Wedge (PCBA Bent, T≥5.2mm) |
| application | Laptop |
| signal interface | LVDS (1 ch, 6-bit) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
