| Nama Wahi | LTN156AT05-H01 |
| Waitohu | Samsung |
| Rahi | 15.6 |
| Taupānga | NBPC |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTN156AT05-H01 61 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.6 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 344.232×193.536 mm |
| outline | 359.3×209.5×5.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%), Hard coating (3H) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 500:1 (Min.) |
| display colors | 262K (6-bit), CIE193160% |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 11S5PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H02 | Samsung | 15.6 | 1366×768 |
| LTN156AT09-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT20-P01 | Samsung | 15.6 | 1366×768 |
| LTN156AT20-P02 | Samsung | 15.6 | 1366×768 |
| LTN156AT20-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT36-W01 | Samsung | 15.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| LP140WD2-TLB1 | LG Display | 14.0 | 1600×900 |
| LP156WF1-TLC1 | LG Display | 15.6 | 1920×1080 |
| LTN140AT20-701 | Samsung | 14.0 | 1366×768 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| TX38D88VC1GAA | KOE | 15.0 | 1024×768 |
