| Nama Wahi | M170EN04 V6 |
| Waitohu | AUO |
| Rahi | 17.0 |
| Taupānga | DMPC |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 400:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AU Optronics |
| panel model | M170EN04 V6 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 383.5×306 mm |
| surface | |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 25/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M170EG01 VA | AUO | 17.0 | 1280×1024 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170EP01 V0 | AUO | 17.0 | 1280×1024 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LTM220M1-L01 | Samsung | 22.0 | 1680×1050 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| M200O3-LA3 | Innolux | 20.0 | 1600×900 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
