| Nama Wahi | M220Z1-L0A |
| Waitohu | Innolux |
| Rahi | 22.0 |
| Taupānga | DMPC |
| Whakatau | 1680×1050 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | CHIMEI INNOLUX |
| panel model | M220Z1-L0A |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 22.0 inch |
| resolution | 1680(RGB)×1050 , WSXGA+ |
| display mode | TN, Normally White, Transmissive |
| active area | 473.76×296.1 mm |
| outline | 493.7×320.1 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| response time | 1.3/3.7 (Typ.)(Tr/Td) |
| viewing angle | 85/85/80/80 (Typ.)(CR＞10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| LM220W1-A2MN | LG Display | 22.0 | 1600×1024 |
| LM220WE1-TLD2 | LG Display | 22.0 | 1680×1050 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L05 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L09 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
| M220Z1-P03 | Innolux | 22.0 | 1680×1050 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
| M220ZGE-L20 | Innolux | 22.0 | 1680×1050 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM240WU8-SLD4 | LG Display | 24.0 | 1920×1200 |
| LM250WW1-SSA1 | LG Display | 25.0 | 2560×1080 |
| LTM150XH-T01 | Samsung | 15.0 | 1024×768 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| M185XW01 VH | AUO | 18.5 | 1366×768 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
