| Nama Wahi | NL160120BC27-09 |
| Waitohu | NLT |
| Rahi | 21.3 |
| Taupānga | DMPC |
| Whakatau | 1600×1200 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 450:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL160120BC27-09 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 21.3 inch |
| resolution | 1600(RGB)×1200 , UXGA |
| display mode | SA-SFT, Normally Black, Transmissive |
| active area | 432×324 mm |
| outline | 457×350×25.5 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 9/11 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 40 pins |
| input voltage | 12.0V (Typ.) |
| application | DMPC |
