| Nama Wahi | LM300W01-STA4 |
| Waitohu | LG Display |
| Rahi | 30.0 |
| Taupānga | DMPC |
| Whakatau | 2560×1600 |
| Te tito | LCM |
| Tirohanga | 380 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | TMDS |
| panel brand | LG.Philips LCD |
| panel model | LM300W01-STA4 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 30.0 inch |
| resolution | 2560(RGB)×1600 , WQXGA |
| display mode | S-IPS, Normally Black, Transmissive |
| active area | 641.28×400.8 mm |
| outline | 677.3×436.8 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 380 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 6/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | Dual Link TMDS, 45 pins |
| input voltage | 18.0V (Typ.) |
| rohs: | |
| application | DMPC |
