| Nama Wahi | M090SWP1 R1 |
| Waitohu | IVO |
| Rahi | 9.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | - |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| panel brand | IVO |
| panel size | 9.0" |
| resolution | 800(RGB)×480, WVGA, 104PPI |
| display area | 198(W)×111.696(H) mm |
| outline size | 211.1(W)×128.4(H) ×7.1(D) mm |
| brightness | - |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 16.7M 50% NTSC |
| frequency | 60Hz |
| weight | - |
| panel model | M090SWP1 R1 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 201.0(W)×114.7(H) mm |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 10/15 (Typ.)(Tr/Td) |
| lamp type | WLED , 20K hours , With LED Driver |
| touch screen | Without |
| application | Industrial |
