| Nama Wahi | LQ070T3AG02 |
| Waitohu | SHARP |
| Rahi | 7.0 |
| Taupānga | VDP |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 60:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | SHARP |
| panel model | LQ070T3AG02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480(RGB)×234 |
| display mode | TN, Normally White, Transmissive |
| active area | 155.52×87.75 mm |
| outline | 176.5×107.5 mm |
| surface | |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 60:1 (Min.) |
| display colors | Full color |
| response time | 30/50 (Typ.)(Tr/Td) |
| viewing angle | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| input voltage | 12.0V (Typ.) |
| application | VDP |
