| Nama Wahi | LQ070T5DG01 |
| Waitohu | SHARP |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 854×480 |
| Te tito | LCM |
| Tirohanga | 410 |
| CR | 60:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ070T5DG01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 854(RGB)×480 , FWVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 155×87.12 mm |
| outline | 176.9×109.3 mm |
| surface | Antiglare |
| brightness | 410 cd/m² (Typ.) |
| contrast ratio | 60:1 (Min.) |
| display colors | 262K (6-bit) |
| response time | 30/50 (Typ.)(Tr/Td) |
| viewing angle | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| input voltage | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| application | CNS |
