| Nama Wahi | LQ070Y3LG4A |
| Waitohu | SHARP |
| Rahi | 7.0 |
| Taupānga | IA |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 400:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SHARP |
| panel model | LQ070Y3LG4A |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800×480(RGB) , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 152.4×91.44 mm |
| outline | 163.2×104×6.25 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 8S3PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
